Identification of Prints: Modern Monochrome printing methods

halftones

I posted already on the use of a USB microscope to identify the oldest manual printing methods, relief, and intaglio.

I now look with my USB microscope at some modern monochrome printing methods to highlights some of their characterizing features. As usual, I don’t discuss the actual printing methods but just how to identify them.

Planographic

Planographic is a large category which encompasses the numerous variant of lithography whose first process was discovered in 1798.  There are wonderful videos on the internet that illustrate how this method is done; just search for “lithography”. Briefly, with the invention of lithography, the artist was freed from any curving and engraving; the artist could just draw as usual but on a prepared stone using specific greasy pencils for lithography. Then the surface is covered with a film of water and then one of ink. This last one will stick only to the greasy drawing and the stone can be etched.

  • Flatness. The general characteristic of lithographic printing is both ink and paper flatness.



lithography
Twenty Euro bill. The architectural details are printed in intaglio and the ink looks raised in raking light. On the other hand, the ink of the background pattern is flat, characteristic of lithography.



lithography
20 Euro bill, verso. Everything on the bill’s verso is lithography (looking flat) except the serial number which is a relief and shows characteristic edges-rim.



Process prints

Also another large category. The term “process” means that the printing block image was not created by a craftsman, but by means of some mechanical, chemical or photochemical process. There were a great number of ingenious methods conceived, starting in 1800, in order to speed up the production of prints.

Gravure

Identify:

  • In an area where different shades of grey merge, the dots are all of much the same size but of different intensity, usually, square in shape and separated by a grid of straight white lines. The ink in the dark areas will submerge the white –line grid entirely, becoming solid grey or black.
  • Gravure differs from relief printing and offset lithography in that it is capable, like any intaglio process, of depositing varying depths of ink.

Halftone prints

A b/w photograph is reduced to pure blacks dots with white spaces by using a screen between the photograph and a light-sensitized surface which will become the actual printing block. The method was fast but low in quality so it was used for newspapers and economic books from the 1880s until 1960s, then replaced by offset lithography.

Halftone printing is identified by:

  • Squeeze-out. This feature is the result of more ink being deposited at the edges of individual dots than at the center.
  • Edge’s rim. In an area where different shades of grey merge, the dots shows clean edge with ink rim



letterpress
Squeeze-out. This feature is the result of more ink being deposited at the edges of individual dots than at the center. “Il Capitano Spaventa”, R. Bemporad e Figlio editori, Firenze, 1924.



Offset Lithography

Light passes through a photograph negative and hit a lithographic plate coated with light-sensitized gelatin. The gelatin hit by light hardens and will take the ink while the soft gelatin is then dissolved by water. The term “offset” means that the ink is not transferred directly from the plate to the paper but is set off from the plate onto an intermediate rubber roller and from that is transferred to the paper.

  • In an area where different shades of grey merge, the dots are of differing size and have a blurred edge, but the ink will lie evenly within the dots.
offset
This is a photo of the reproduction of a wood engraving published in “How to identify prints [1]”. The dots’ size and shape clearly indicate offset lithographic printing.

Laser printers

Xerography (electrostatic printing) is the process used in photocopy machines and in laser printers. The black lines of a xerox image are made up of thousands of tiny dust-like grains of pigment. A few specks of pigment are not inline and is these deviants which give the method away.



Inkjet printers

In inkjet printers lines and letters will have a much softer edge than in an original print.

printers
I printed a full stop on both a laser printer and an inkjet printer. Laser printing shows some tiny dust-like grains of pigment not inline.

4 thoughts on “Identification of Prints: Modern Monochrome printing methods

  1. What is the best way to tell an authentic trading card from a fake one?

    With modern printing techniques trading cards can easily be faked. (Think of how $100 bills have been counterfieted) What you can do to protect yourself is to educate yourself on how to identify printing techniques and paper materials. Here is some inf…

  2. Hello! Thank you for this helpful, informative article! I have a work on paper, a black and white line drawing, and I’m trying to determine if it’s a print of some kind (It would date to the mid 1950s) or an original illustration. The paper is textured/toothy like that used for watercolors or pen-and-ink, and I see no dots at all under a jeweler’s loupe (wish I had access to a microscope!). Can you give me any advice on what other clues to look for? Or printing terms to look into (if it could be a print)? Thank you!

    1. Hi Laura,
      I strongly suggest you go to antique shops, better if specialized to works on paper. There you could get good advice from in person examination of the piece. Evaluation of prints could be pretty tough in particular for objects after 1950′.

      1. That’s good advice…thank you!
